8pcs L76 2200cc Injectors 210lb for Pontiac G8 GT 2008–2009
8pcs L76 2200cc Injectors 210lb for Pontiac G8 GT 2008–2009
All wiring harness orders will be shipped after our engineer Nathan confirms the details by email.
These Bosch 2200cc injectors are suitable for the bosch 210 injectors LS3 / L76 engine of the 2008–2009 Pontiac G8 GT, 2020 Ginetta Akula, 2008–2010 Holden WM Statesman/Caprice, 2007–2009 Chevrolet Suburban 1500, Avalanche, Silverado. Set of 8 high performance brand new Bosch 210 injectors with retail box in stock. The high impedance 2200cc injectors include 14mm top and bottom o-rings.
Product Detail:
The fuel lines must be cleaned before replacing the fuel injectors.
Name: BOSCH NGI-2-K
Quantity: 8 fuel injectors (1 piece/box)
Overall Length: 49mm
O-ring seat to seat Dimension: 34mm
Top o-ring: 14mm
Bottom o-ring: 14mm
Injector Body Diameter: 15.2mm
O-ring centerline to centerline Dimension: 38mm
Connector: Bosch (Comes with EV6 / EV1 / OBD2 / Denso PNP connectors)
Static flow rate: 210lb/hr @ 43.5PSI (3BAR) w/Gas 2200cc/min
Dead time: 0.45ms at 14 volts
Coil resistance: 9.1 Ohms / High Impedance
Spray pattern: Conical (30 degree)
Spray angle: Neutral (0 degree)
Acceptable fuels: Gas/Petrol, alcohol/methanol, E85, CNG
L76 engine:
2008–2009 Pontiac G8 GT
2008–2010 Holden VE Commodore (automatic only)
2008–2010 Holden VE Ute (automatic only)
2008–2010 Holden WM Statesman/Caprice
2020 Ginetta Akula
2007–2009 Chevrolet Suburban 1500
2007–2009 GMC Yukon XL
2007–2009 Chevrolet Avalanche
2007–2009 Chevrolet Silverado
2007–2009 GMC Sierra
2006 Holden VZ Commodore - Those built from February 2006 until July 2006 until the release of the VE series.
2006 Holden WL Statesman/Caprice - Those built from February 2006 until September 2006 until the release of the WM series.
