8pcs 2200cc LS4 Injectors 210lb for Chevrolet Impala SS 2006–2009

Set of 8 high impedance saturated ball & seat Bosch 210 injectors sold with retail box. The high performance Bosch 2200cc injectors designed to seamlessly fit LS4 engine, installation is straightforward. Direct plug and play for LS4 engine including Chevrolet Impala SS 2006–2009, Chevrolet Monte Carlo SS 2006–2007, Buick LaCrosse Super 2008–2009.

Product Detail:

The fuel lines must be cleaned before replacing the fuel injectors.

Name: BOSCH NGI-2-K
Quantity: 8 fuel injectors (1 piece/box)
Overall Length: 49mm
O-ring seat to seat Dimension: 34mm
Top o-ring: 14mm
Bottom o-ring: 14mm
Injector Body Diameter: 15.2mm
O-ring centerline to centerline Dimension: 38mm
Connector: Bosch (Comes with EV6 / EV1 / OBD2 / Denso PNP connectors)
Static flow rate: 210lb/hr @ 43.5PSI (3BAR) w/Gas 2200cc/min
Dead time: 0.45ms at 14 volts
Coil resistance: 9.1 Ohms / High Impedance
Spray pattern: Conical (30 degree)
Spray angle: Neutral (0 degree)
Acceptable fuels: Gas/Petrol, alcohol/methanol, E85, CNG

LS4 engine:

2005–2008 Pontiac Grand Prix GXP
2006–2009 Chevrolet Impala SS
2006–2007 Chevrolet Monte Carlo SS
2008–2009 Buick LaCrosse Super
